Mechanical |
|---|
Dimensions |
442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72") |
Weight
With Rackmount Brackets |
4.30 kg (9.48 lb)
4.39 kg (9.68 lb) |
Interfaces
Networking
Management |
(24) 10/100/1000 RJ45 Ports
(2) 1/10G SFP+ Ethernet Ports
Ethernet In-Band |
Total Non-Blocking Throughput |
44 Gbps |
Switching Capacity |
88 Gbps |
Forwarding Rate |
65.472 Mpps |
Power Method
Universal Input
USP RPS DC Input |
100-240VAC/50-60 Hz
52VDC, 7.69A; 11.5VDC, 2.61A |
Power Supply |
AC/DC, Internal, 450W |
Supported Voltage Range |
100 to 240VAC |
Max. Power Consumption (Excluding PoE Output) |
50W |
LEDs
System
RJ45 Data Ports
SFP+ Data Ports |
Status
PoE; Speed/Link/Activity
Link/Activity |
ESD/EMP Protection |
Air: ± 16 kV, Contact: ± 12 kV |
Shock and Vibration |
ETSI300-019-1.4 Standard |
Operating Temperature |
-5 to 40° C (23 to 104° F) |
Operating Humidity |
10 to 90% Noncondensing |
Certifications |
CE, FCC, IC |
PoE |
|---|
Total Available PoE |
400W |
PoE Interfaces
Ports 1-16
Ports 17-24 |
POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-)
60W PoE++ IEEE 802.3af/at/bt (Pins 1, 2+; 3, 6-) (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) |
Max. PoE Wattage per Port by PSE
802.3at
802.3bt |
32W
64W |
Voltage Range 802.3af Mode |
44-57V |
Voltage Range 802.3at Mode |
50-57V |
*Background noise level: 27.5 dBa
