Mechanical |
|---|
Dimensions |
O206 x 46 mm (O8.1 x 1.8") |
Weight |
680 g (1.5 lb) |
Enclosure material |
Polycarbonate, aluminum |
Mount material |
Stainless steel (SUS304), galvanized steel (SGCC) |
Hardware |
|---|
Networking interface |
(1) 1/2.5 GbE RJ45 port |
Management interface |
Ethernet |
|
Power method |
PoE+ |
Power supply |
UniFi PoE switch |
Supported voltage range |
44—57V DC |
Max. power consumption |
22W |
Max. TX power
2.4 GHz
5 GHz
6 GHz |
23 dBm
29 dBm
23 dBm |
MIMO
2.4 GHz
5 GHz
6 GHz |
2 x 2
4 x 4
2 x 2 |
Throughput rate
2.4 GHz
5 GHz
6 GHz |
688 Mbps
8648 Mbps
5765 Mbps |
Antenna gain
2.4 GHz
5 GHz
6 GHz |
4 dBi
6 dBi
5.9 dBi |
LEDs |
White/blue |
Button |
Factory reset |
Mounting |
Wall, ceiling (Included) |
Ambient operating temperature |
-30 to 60° C (-22 to 140° F) |
Ambient operating humidity |
5 to 95% noncondensing |
Certifications |
CE, FCC, IC |
Software |
|---|
WiFi standards |
802.11a/b/g/n/ac/ax/be |
Wireless security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
BSSID |
8 per radio |
VLAN |
802.1Q |
Advanced QoS |
Per-user rate limiting |
Guest traffic isolation |
Supported |
Concurrent clients |
500+ |
Supported Data Rates |
|---|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b |
1, 2, 5.5, 11 Mbps |
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
802.11ac (WiFi 5) |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
802.11ax (WiFi 6/6E) |
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
802.11be (WiFi 7)
5 GHz
6 GHz |
7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320) |
Application Requirements |
|---|
UniFi Network |
Version 8.2.93 and later |
