Mechanical |
|---|
Dimensions |
170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1") |
Weight |
1.2 kg (2.6 lb) |
Enclosure material |
UV-stabilized polycarbonate, aluminum alloy |
Mount material |
Polycarbonate, SGCC steel |
Pole mount diameter |
25–60 mm (1–2.36") on pipe outer diameter |
Wind survivability |
74.6 N at 200 km/h (16.8 lbf at 125 mph) |
Weatherproofing |
IPX6 |
Hardware |
|---|
Networking interface |
(1) 1/2.5 GbE RJ45 port |
Management interface |
Ethernet |
Power method |
PoE+ |
Power supply |
UniFi PoE Switch |
Supported voltage range |
42.5—57V DC |
Max. power consumption |
19W |
Max. TX power
2.4 GHz
5 GHz
6 GHz |
23 dBm
26 dBm
– |
MIMO
2.4 GHz
5 GHz
6 GHz |
2 x 2
2 x 2
– |
Throughput rate
2.4 GHz
5 GHz
6 GHz |
688 Mbps
4324 Mbps
– |
Antenna gain
2.4 GHz
5 GHz
6 GHz |
Directional internal: 8 dBi / External omni: 3 dBi
Directional internal: 12.5 dBi / External omni: 4 dBi
– |
Antenna beamwidth
2.4 GHz
5 GHz
6 GHz |
90°
45°
– |
Antennas |
(1) Directional internal antenna
(2) External omni antennas
(2) RP-SMA connectors for external antenna |
LEDs |
(1) Power: white/blue
(4) Mesh signal: blue |
Button |
Factory reset |
Mounting |
Wall, ceiling, pole (Included) |
Ambient operating temperature |
-30 to 60° C (-22 to 140° F) |
Ambient operating humidity |
5 to 95% noncondensing |
Certifications |
CE, FCC, IC |
Software |
|---|
WiFi standards |
802.11a/b/g/n/ac/ax/be |
Wireless security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
BSSID |
8 per radio |
VLAN |
802.1Q |
Advanced QoS |
Per-user rate limiting |
Guest traffic isolation |
Supported |
Concurrent clients |
200+ |
Supported Data Rates |
|---|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b |
1, 2, 5.5, 11 Mbps |
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
802.11ac (WiFi 5) |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
802.11ax (WiFi 6) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
802.11be (WiFi 7) |
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) |
