Mechanical |
|---|
Dimensions |
O 110 x 184.2 mm (O 4.33 x 7.25") |
Weight |
1.05 kg (2.32 lb) |
Networking Interfaces |
(4) LAN 10/100/1000 RJ45 Ports
(1) WAN 10/100/1000 RJ45 Port |
Buttons |
Reset |
IDS/IPS Throughput |
850 Mbps |
Processor |
Arm Cortex-A57 Quad-Core at 1.7 GHz |
System Memory |
2 GB DDR RAM |
On-Board Flash Storage |
16 GB |
Maximum Power Consumption |
26W |
Supported Voltage Range |
100 - 240VAC |
Power Method |
AC Power Cord |
Power Supply |
Internal AC/DC Power Adapter (24V, 0.6A, 100 - 240VAC) |
Power Save |
Supported |
Beamforming |
Supported |
TX Power*
2.4 GHz
5 GHz |
23 dBm
26 dBm |
Antenna |
(1) Dual-Band, Quad-Polarity Antenna |
Antenna Gain
2.4 GHz
5 GHz |
3 dBi
4.5 dBi |
Wi-Fi Standards |
802.11 a/b/g/n/ac/ac-wave2 |
Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF |
BSSID |
Up to 8 per Radio |
Operating Temperature |
-10 to 45° C (14 to 113° F) |
Operating Humidity |
5 to 95% Noncondensing |
Certifications |
CE, FCC, IC |
* Including antenna gain. Maximum TX power level may be limited by user's country-specific regulations.
