Mechanical |
|---|
Dimensions |
O220 x 48.1 mm (O8.66 x 1.89") |
Weight |
Without mount: 960 g (2.1 lb)
With mount: 1090 g (2.4 lb) |
Enclosure materials |
Top housing: plastic
Bottom housing: aluminum |
Mount material |
SGCC steel |
Hardware |
|---|
Management interface |
Ethernet
Bluetooth |
Networking interface |
(1) 2.5GbE RJ45 port |
Button |
Reboot and factory-reset |
LED |
W/B |
Power method |
PoE+ |
Power supply |
UniFi PoE switch
48V, 0.5A PoE adapter (optional) |
Supported voltage range |
44 - 57VDC |
Max. power consumption |
22W |
Max. TX power
2.4 GHz
5-7 GHz |
22 dBm
26 dBm |
MIMO
2.4 GHz
5 GHz
6 GHz |
2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO) |
Throughput rate
2.4 GHz
5 GHz
6 GHz |
573.5 Mbps
4.8 Gbps
4.8 Gbps |
Antenna gain
2.4 GHz
5 GHz
6 GHz |
3.2 dBi
5.3 dBi
6 dBi |
Mounting |
Wall/ceiling (included) |
Operating temperature |
-30 to 60° C (-22 to 140° F) |
Operating humidity |
5 - 95% noncondensing |
Certifications |
CE, FCC, IC |
Software |
|---|
WiFi standards |
802.11a/b/g
WiFi 4/WiFi 5/WiFi 6/WiFi 6E |
Wireless security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
BSSID |
8 per radio |
VLAN |
802.1Q |
Advanced QoS |
Per-user rate limiting |
Guest traffic isolation |
Supported |
Concurrent clients |
600+ |
Zero wait DFS |
Yes |
Supported Data Rates (Mbps) |
|---|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b |
1, 2, 5.5, 11 Mbps |
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (WiFi 4) |
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
802.11ac (WiFi 5) |
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
802.11ax (WiFi 6/6E) |
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
