Specifications
Details |
|---|
Product code |
RB5009UPr+S+IN |
Architecture |
ARM 64bit |
CPU |
88F7040 |
CPU core count |
4 |
CPU nominal frequency |
350-1400 (auto) MHz |
RouterOS license |
5 |
Operating System |
RouterOS |
Size of RAM |
1 GB |
Storage size |
1 GB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 60°C |
Suggested price |
$299.00 |
Powering
Details |
|---|
Number of DC inputs |
3 (PoE-IN, DC jack, 2-pin terminal) |
DC jack input Voltage |
24-57 V |
2-pin terminal input Voltage |
24-57 V |
Max power consumption |
150 W |
Max power consumption without attachments |
15 W |
Cooling type |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
24-57 V |
PoE-out
Details |
|---|
PoE-out ports |
Ether1-Ether8 |
PoE out |
802.3af/at |
Max out per port output (input 18-30 V) |
640 mA |
Max out per port output (input 30-57 V) |
420 mA |
Max total out (A) |
2.59 A |
Total output current |
2.28 |
Total output power |
130 |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
7 |
Number of 1G Ethernet ports with Reverse PoE (PoE-in) |
7 |
Number of 2.5G Ethernet ports |
1 |
Number of 2.5G Ethernet ports with PoE-out |
1 |
Fiber
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB 3.0 type A |
Max USB current (A) |
1 |
Other
Details |
|---|
CPU temperature monitor |
Yes |
Current Monitor |
Yes |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
20 |
Included parts
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
