Specifications
Details |
|---|
Product code |
CRS518-16XS-2XQ-RM |
Architecture |
MIPSBE |
CPU |
QCA9531 |
CPU core count |
1 |
CPU nominal frequency |
650 MHz |
RouterOS license |
6 |
Operating System |
RouterOS |
Size of RAM |
64 MB |
Storage size |
16 MB |
Storage type |
FLASH |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 70°C |
Suggested price |
$1595.00 |
Powering
Details |
|---|
Number of AC inputs |
2 |
AC input range |
100-240 |
Frequency (Hz) |
47-63 |
Max power consumption |
77 W |
Max power consumption without attachments |
45 W |
Cooling type |
4 fans |
Ethernet
Details |
|---|
10/100 Ethernet ports |
1 |
Fiber
Details |
|---|
Number of 25G SFP28 ports |
16 |
Number of 100G QSFP28 ports |
2 |
Peripherals
Details |
|---|
Serial console port |
RJ45 |
Number of USB ports |
1 |
USB slot type |
USB type A |
Max USB current (A) |
1 |
Other
Details |
|---|
CPU temperature monitor |
Yes |
PCB temperature monitor |
Yes |
Voltage Monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
IP |
20 |
Included parts
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
