Essentials
Download Specifications
Product Collection
Intel® Wi-Fi 6E (Gig+) Series
Code Name
Products formerly Typhoon Peak
Marketing Status
Launched
Launch Date
Q4'20
Weight (in grams)
2.8
Operating Temperature Range
0°C to 80°C
Operating Temperature (Maximum)
80 °C
Operating Temperature (Minimum)
0 °C
Supported Operating Systems
Windows 11, 64-bit*, Windows 10, 64-bit*, Linux*
Antenna
2x2
Supplemental Information
Product Brief
View now
Networking Specifications
TX/RX Streams
2x2
Bands
2.4, 5, 6 GHz (160MHz)
Max Speed
2.4 Gbps
Wi-Fi CERTIFIED*
Wi-Fi 6E (802.11ax)
Compliance
FIPS, FISMA
Integrated Bluetooth
Yes
Bluetooth Version
5.3
Package Specifications
Board Form Factor
M.2 2230, M.2 1216
Package Size
22mm x 30mm x 2.4mm, 12mm x 16mm x 1.65mm
System Interface Type
Wi-Fi(PCIe), BT(USB)
Advanced Technologies
MU-MIMO
Yes
Orthogonal Frequency-Division Multiple Access (OFDMA)
Yes
Supported Under Intel vPro® Technology
Yes
