Részletek

Essentials

• Product CollectionIntel® Core™ i9 Processors (14th gen)


• Code NameProducts formerly RAPTOR LAKE


• Vertical SegmentDesktop


• Processor Numberi9-14900K


• LithographyIntel 7


• Use ConditionsPC/Client/Tablet, Workstation



CPU Specifications

• Total Cores24


• # of Performance-cores8


• # of Efficient-cores16


• Total Threads32


• Max Turbo Frequency6 GHz


• Intel® Thermal Velocity Boost Frequency6 GHz


• Intel® Turbo Boost Max Technology 3.0 Frequency ^‡5.8 GHz


• Performance-core Max Turbo Frequency5.6 GHz


• Efficient-core Max Turbo Frequency4.4 GHz


• Performance-core Base Frequency3.2 GHz


• Efficient-core Base Frequency2.4 GHz


• Cache36 MB Intel® Smart Cache


• Total L2 Cache32 MB


• Processor Base Power125 W


• Maximum Turbo Power253 W

Supplemental Information

• Marketing StatusLaunched


• Launch DateQ4'23


• Embedded Options AvailableNo

Memory Specifications

• Max Memory Size (dependent on memory type)192 GB


• Memory TypesUp to DDR5 5600 MT/s
  Up to DDR4 3200 MT/s


• Max # of Memory Channels2


• Max Memory Bandwidth89.6 GB/s


• ECC Memory Supported ^‡Yes

GPU Specifications

• Processor Graphics ^‡Intel® UHD Graphics 770


• Graphics Base Frequency300 MHz


• Graphics Max Dynamic Frequency1.65 GHz


• Graphics OutputeDP 1.4b, DP 1.4a, HDMI 2.1


• Execution Units32


• Max Resolution (HDMI)^‡4096 x 2160 @ 60Hz


• Max Resolution (DP)‡7680 x 4320 @ 60Hz


• Max Resolution (eDP - Integrated Flat Panel)‡5120 x 3200 @ 120Hz


• DirectX* Support12


• OpenGL* Support4.5


• OpenCL* Support3.0


• Multi-Format Codec Engines2


• Intel® Quick Sync VideoYes


• Intel® Clear Video HD TechnologyYes


• # of Displays Supported ^‡4


• Device ID0xA780

Expansion Options

• Direct Media Interface (DMI) Revision4.0


• Max # of DMI Lanes8


• Scalability1S Only


• PCI Express Revision5.0 and 4.0


• PCI Express Configurations ^‡Up to 1x16+4, 2x8+4


• Max # of PCI Express Lanes20

Package Specifications

• Sockets SupportedFCLGA1700


• Max CPU Configuration1


• Thermal Solution SpecificationPCG 2020A


• T_JUNCTION100°C


• Package Size45.0 mm x 37.5 mm

Advanced Technologies

• Intel® Gaussian & Neural Accelerator3.0


• Intel® Thread DirectorYes


• Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes


• Intel® Speed Shift TechnologyYes


• Intel® Adaptive Boost TechnologyYes


• Intel® Thermal Velocity BoostYes


• Intel® Turbo Boost Max Technology 3.0 ^‡Yes


• Intel® Turbo Boost Technology ^‡2.0


• Intel® Hyper-Threading Technology ^‡Yes


• Intel® 64 ^‡Yes


• Instruction Set64-bit


• Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2


• Idle StatesYes


• Enhanced Intel SpeedStep® TechnologyYes


• Thermal Monitoring TechnologiesYes


• Intel® Volume Management Device (VMD)Yes

Security & Reliability

• Intel® Standard Manageability (ISM) ^‡Yes


• Intel® Control-Flow Enforcement TechnologyYes


• Intel® AES New InstructionsYes


• Secure KeyYes


• Intel® OS GuardYes


• Execute Disable Bit ^‡Yes


• Intel® Boot GuardYes


• Mode-based Execute Control (MBEC)Yes


• Intel® Virtualization Technology (VT-x) ^‡Yes


• Intel® Virtualization Technology for Directed I/O (VT-d) ^‡Yes


• Intel® VT-x with Extended Page Tables (EPT) ^‡Yes
